Four Head PVC UPVC Window Machine 400-4500mm Welding Length Customized Power Supply

Model Number : SHZ4-100X4500

Certification : CE ISO

MOQ : 1set

Price : By negotiation

Supply Ability : 30 sets per month

Delivery Time : 20 days

Packaging Details : 1, plastic stretch film coating; 2, steel pallet and plywood case package; 3, LCL or FCL by sea transportation;

Function : Window Corner Welding

Welding scale : 100x120mm

Welding length : 400-4500mm

Air pressure : 0.5-0.8MPa

Total power : 4.5Kw

Product : PVC UPVC Window Welding Machine for Window Corner Assembling

Contact Now

Four Head PVC UPVC Window Machine for Window Corner Welding

Introduction

Four Head PVC UPVC Window Machine for Window Corner Welding

1, Suitable for welding common PVC UPVC profile, color coated PVC profile and laminated PVC profile.

2, Adopt programmable logic controller (PLC) ensures the machine running more stable and reliable.

3, Double pressing function ensures higher welding strength.

4, The pressure of front and back clamper is adjusted separately, so as to improve the planeness of the welding corner

5, The heads are operated individually, together.

6, No. 2,3,4 head can move horizontally, so that realize various kinds of welding combination.

7, The fourth head can be used for welding variable angle with the special mold and the angle range from 30°~180°.

8, Professional mold configuration, can provide the design for different profiles ensure the welding quality. (optional)

9, Welding seam is about 0.10-0.15mm.

10, single head, double head and triple head welding machine available.

Parameter

Parameters of Care PVC welding machine
Options	single head	double head	triple head	four head
Power supply	380V 50Hz 3P (or customized)
Total power	1.2KW	2.5KW	3.5KW	4.5KW
Air pressure	0.5-0.8MPa
Welding scale (WxHxL)	120x120x1800mm	120x120x3500mm	120x120x3500mm	120x120x4500mm H=170mm customized
Dimension L×W×H	960x900x1460mm	4300x900x1650mm	4300x900x1650mm	5300x900x1650mm

Flow chart

Four Head PVC UPVC Window Machine 400-4500mm Welding Length Customized Power Supply

Our Services

Four Head PVC UPVC Window Machine 400-4500mm Welding Length Customized Power Supply
